Carbon Fiber Round Tube

Q: What kinds of carbon fiber round tube fabric material your factory used?

ChatGPT 说： We mainly use 3K resin prepreg bi-directional carbon fiber fabric, but 1K, 6K, and unidirectional options are also available. Material grades include T300, T700, T800, and M-series fibers for varying strength and performance needs.

Home » Custom Carbon Fiber Tube » Carbon Fiber Round Tube

3 Inch OD 90 Degree Carbon Fiber Tube Factory

Alizn Professional Customization

Custom Carbon Fiber Round Tubes Catalog

Alizn custom carbon fiber round tubes are carefully crafted using only the finest materials. Our production team offers superior craftsmanship with over 10 years of experience working with custom carbon fiber straight / bent / flat / rectangular / intake tube.

Custom Carbon Fiber Tube Specification

Choose Inner - outer diameters

Alizn offers a wide range of carbon fiber tube sizes with outer diameters from 5mm to 128mm. Each tube is manufactured using precision molds to ensure excellent roundness, uniform wall thickness, and consistent tolerances, making it an ideal choice for OEM manufacturing.

OD (mm)	ID (mm)	OD (inch)	ID (inch)
5.0	3.0	0.197	0.118
6.0	4.0	0.236	0.157
7.0	5.0	0.276	0.197
7.0	6.0	0.276	0.236
8.0	6.0	0.315	0.236
8.0	7.0	0.315	0.276
10.0	8.0	0.394	0.315
10.0	9.0	0.394	0.354
12.0	10.0	0.472	0.394
12.0	11.0	0.472	0.433
13.0	11.0	0.512	0.433
14.0	12.0	0.551	0.472
14.0	13.0	0.551	0.512
15.0	10.0	0.591	0.394
15.0	13.0	0.591	0.512
16.0	12.0	0.630	0.472
16.0	14.0	0.630	0.551
16.0	15.0	0.630	0.591
18.0	16.0	0.709	0.630
18.0	17.0	0.709	0.669
19.0	17.0	0.748	0.669
20.0	18.0	0.787	0.709
22.0	20.0	0.866	0.787
22.0	21.0	0.866	0.827
23.0	21.0	0.906	0.827
23.0	22.0	0.906	0.866
24.0	22.0	0.945	0.866
25.0	23.0	0.984	0.906
26.0	24.0	1.024	0.945
27.0	25.0	1.063	0.984
28.0	26.0	1.102	1.024
29.0	25.0	1.142	0.984
30.0	26.0	1.181	1.024
30.0	27.0	1.181	1.063
30.0	28.0	1.181	1.102
32.0	30.0	1.260	1.181
35.0	33.0	1.378	1.299
36.0	34.0	1.417	1.339
38.0	36.0	1.496	1.417
40.0	36.0	1.575	1.417
40.0	38.0	1.575	1.496
42.0	40.0	1.654	1.575
45.0	42.0	1.772	1.654
47.0	44.0	1.850	1.732
48.0	45.0	1.890	1.772
49.0	46.0	1.929	1.811
50.0	48.0	1.968	1.890
53.0	50.0	2.087	1.969
54.0	50.0	2.126	1.969
55.0	52.0	2.165	2.047
58.0	54.0	2.283	2.126
58.0	55.0	2.283	2.165
59.0	56.0	2.323	2.205
60.0	57.0	2.362	2.244
62.0	58.0	2.441	2.283
63.0	60.0	2.480	2.362
65.0	62.0	2.559	2.441
68.0	64.0	2.677	2.520
70.0	66.0	2.756	2.598
72.0	68.0	2.835	2.677
74.0	70.0	2.913	2.756
76.0	72.0	2.992	2.835
76.0	73.0	2.992	2.874
78.0	74.0	3.071	2.913
80.0	76.0	3.150	2.992
82.0	78.0	3.228	3.071
84.0	80.0	3.307	3.150
86.0	82.0	3.386	3.228
88.0	84.0	3.465	3.307
90.0	86.0	3.543	3.386
92.0	88.0	3.622	3.465
94.0	90.0	3.701	3.543
96.0	92.0	3.780	3.622
98.0	94.0	3.858	3.701
100.0	96.0	3.937	3.780
102.0	98.0	4.016	3.858
104.0	100.0	4.094	3.937
106.0	102.0	4.173	4.016
108.0	104.0	4.252	4.094
110.0	106.0	4.331	4.173
112.0	108.0	4.409	4.252
114.0	110.0	4.488	4.331
116.0	112.0	4.567	4.409
118.0	114.0	4.646	4.488
120.0	116.0	4.724	4.567
122.0	118.0	4.803	4.646
124.0	120.0	4.882	4.724
126.0	122.0	4.961	4.803
128.0	124.0	5.039	4.882

Custom Carbon Fiber Tube Material

Choose weave and filament count

Select custom custom carbon+fiber+round+tube weave pattern and filament count for optimal strength and performance, with full customization options to meet any specification or requirement

Custom Carbon Fiber Tube Appearance

Choose Finishes

Fabrics & Finishes and Color To Meet Your Needs

Carbon Fiber Tube Customization Case

Custom Carbon Fiber Tube SHOW

With advanced technology and expert craftsmanship, we create durable, high-performance custom carbon fiber products tailored to each project’s needs. From initial prototypes to large-scale production, we ensure top-quality results and help you achieve your manufacturing goals.

carbon fiber tubes 100mm — carbon fiber straight tube 100mm outer diameter, 96mm inner diameter, and 2mm wall thickness, glossy finish and 2×2 twill weave

10mm carbon fiber tubes customer review — carbon fiber straight tube 10mm outer diameter, 8mm inner diameter, and 1mm wall thickness, glossy finish and 2×2 twill weave

1 inch carbon fiber tubes customer review — carbon fiber straight tube 1 inch outer diameter and 2mm thickness, glossy finish and 2×2 twill weave

1 inch carbon fiber pultruded tubes — carbon fiber pultruded tube1inch outer diameter, 1mm thickness, matte finish, unidirectional texture (pultruded)

1.25 inch carbon fiber tubes customer show — carbon fiber straight tube 1.25 inch outer diameter and 1mm thickness, glossy finish and 2×2 twill weave pipe

1 inch carbon fiber square tube 25×25mm customer show — carbon fiber square tube 25×25mm (1 inch) outer size and 1.5mm wall thickness, glossy finish and 3K twill weave pipe.

pultruded carbon fiber tube 0.5 inch customer show — pultruded carbon fiber tube, 1/2 inch outer diameter, unidirectional weave solid carbon fiber pipe

carbon fiber spearfishing barrel tube customer show — 31mm OD carbon fiber spearfishing barrel tube, 25.4mm(1") inter diameter, 2.8mm Thickness, twill rolling pipe

different specifications carbon fiber tube customer show — carbon fiber tubes of different specifications, 20-25mm outer diameter, 1-1.5mm thickness, length 200-300mm pipe

7 8 carbon fiber round tubes customer show — carbon fiber round tube 7/8 inch outer diameter and 1mm thickness, matte finish and 2×2 twill weave carbon fiber pipe

1.25 carbon fiber tubing customer show — 1.25 inch carbon fiber tubing 32mm outer diameter and 1mm thickness, glossy finish and 4×4 twill weave carbon fiber pipe

30mm carbon fiber tubes customer show — 30mm carbon fiber straight tubing 26mm inter diameter and 2mm thickness, matte finish and 2×2 twill weave pipe

20.7mm carbon fiber tubes customer show — 20.7mm od straight carbon fiber tube, 18mm inter diameter, length 150mm(5.9"), 1.85mm thickness, 3K twill carbon fiber pipe

Upload Your CAD File

To begin, provide your contact details and upload the CAD file or specific dimensions of your design. This allows us to create a detailed 3D model of the part or prototype you're looking to custom carbon fiber round tubes.

Receive a Quote & Design Review

Within 12 hours, we’ll send you a detailed quote along with Design for Manufacturability (DFM) feedback. This ensures the feasibility of your project and gives you a clear idea of the costs involved.

Confirm Your Order & Begin Production

Once you approve the quote and design, we’ll proceed with the production of your custom carbon fiber round tubes.

Shipping & Delivery

Your project enters our manufacturing queue the morning after we receive your approval. On average, custom orders ship within 10-15 business days. In-stock products and samples ship within 48 hours.

Just 4 Steps
Custom Carbon Fiber Round Tube Quotation Process

From detailed consultation to final delivery, we make custom parts orders simple and easy. We pride ourselves on providing exceptional customer service by anticipating your needs, offering customized solutions and on-time delivery.

Carbon Fiber Customization Process

From Design to Quality Control
Every Step Tailored to Perfection

Alizn carbon fiber customization process ensures precision, quality, and efficiency at every stage. From innovative design and advanced production to rigorous quality control, we transform your ideas into high-performance solutions. Serving diverse industries, we specialize in creating prototypes and full-scale production, turning your vision into reality with unmatched expertise and attention to detail.

Professional Equipment For Carbon Fiber

The Equipment Behind Custom Carbon Fiber Round Tube

Our professional equipment provides complete solution for carbon fiber round tubes customization, ensuring high precision, efficiency, and cost-effectiveness.
From design to production, we meet strict quality standards, addressing complex shapes and performance needs.

Carbon Fiber Tube Professional Guide

Custom Carbon Fiber Tube Knowledge

Alizn explores with you every factor that influences your choice
design, functionality, durability, brand positioning, price factors, process, customization options

Carbon Fiber Tube Manufacturing Process

Carbon fiber tubes – including round tubes, square (rectangular) tubes, and telescopic tubes – are made through a variety of

Carbon Fiber Tube VS. Traditional Materials Tubes

In the evolving world of engineering and manufacturing, the choice of materials determines the performance, efficiency, and longevity of the

Carbon Fiber Rectangular Tube Manufacturing Guide

As a carbon fiber parts manufacturer, Alizn understands why customers are increasingly turning to carbon fiber rectangular tubes for structural,

Custom Carbon Fiber Round Tube FAQs

Alizn specialize in precision parts crafted from high-performance custom carbon fiber, ideal for functional tests or end-use applications. Explore our FAQs to discover more about our carbon fiber solutions and related technical support.

What kinds of carbon fiber round tube fabric material your factory used?

We mainly use 3K resin prepreg bi-directional carbon fiber fabric, but 1K, 6K, and unidirectional options are also available. Material grades include T300, T700, T800, and M-series fibers for varying strength and performance needs.

What carbon fiber round tubes surface you have?

Plain/twill weave with glossy/matte clear coating. And also we have unidirectional fabric without any weave surface. In additional, we have forged carbon fiber texture weave. You can choose what you want and let us know.

How can we get a quote?

We need 3 details: 1. step/stp/x_t format drawing file; 2. quantity; 3. surface requirement.

What’s the lead time of carbon fiber round tubes sample?

Mold time 25-30 days; and sample time 7-10 days;

Can you help us to draft drawing file?

Yes, we can. But we need samples to scan the dimension or you can provide very detailed dimension to us. We can draft drawing file with surcharge.

What if I can’t find the model I need in the standard customization list?

Alizn offers moulds that cover almost all standard models of carbon fiber tubes available on the market. If the specific model you need is not available, we can customize a mould first, and then proceed with product manufacturing based on your specifications.

What’s the carbon+fiber+round+tubes mold material?

Aluminium mold, steel mold, fiberglass mold and carbon fiber mold, steel mold with high precision since it is hard and produced by machining, so steel mold is the best option. For inside mold, normally with metal mold, or airbag core or silcone core.

What’s the carbon fiber round tube production method?

Our carbon fiber products can be manufactured according to customer requirements using techniques such as autoclave moulding, filament winding, pultrusion, and rolling moulding to ensure high strength, lightweight structure, and excellent surface quality.
